Threaded 1000WOG Stainless Steel Ball Valve 2057N Type CF8M Material

Suzhou Ephood Automation Equipment Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Threaded 1000WOG Stainless Steel Ball Valve 2057N Type CF8M Material from wholesalers

    Buy cheap Threaded 1000WOG Stainless Steel Ball Valve 2057N Type CF8M Material from wholesalers
    • Buy cheap Threaded 1000WOG Stainless Steel Ball Valve 2057N Type CF8M Material from wholesalers

    Threaded 1000WOG Stainless Steel Ball Valve 2057N Type CF8M Material

    Ask Lasest Price
    Brand Name : SUFA
    Model Number : Q41F
    Certification : (DNV)ISO9001,(DNV)ISO14001,CE0035
    Price : Negotiation
    Payment Terms : T/T, Western Union, MoneyGram, L/C, D/P
    Supply Ability : 500PCS per month
    Delivery Time : within 8-12 working days upon receipt of payment
    • Product Details
    • Company Profile

    Threaded 1000WOG Stainless Steel Ball Valve 2057N Type CF8M Material

    2057N Type CF8M Material Threaded 1000WOG 3 Way Ball Valve In Ball Valves


    Design Features

    1. Adjustable fire-safe stem packing
    2. Machined fire-lip act as meta backup seat has excellent fire-safe capability
    3. Anti-blow out stem
    4. Anti-static device
    5. Full rated bi-directional shut-off
    6. Optional lockable handle
    7. Spiral wound gasket,prevent external leakage
    8. Full rated dead end service


    Main Parameter Specifications

    - L port or T port , 1/2" (DN15) 3 way ball valve ,1000wog ball valve

    - Working Pressure : 1000psi (PN64)

    - Working Temperature: -20°C~200°C(-4ºF~392ºF)

    - Investment casting

    - Blow-out proof stem

    - Locking device

    - Anti-static device (option)

    - ISO 5211 mounting pad

    - Thread type: ASME B1.20.1(NPT) DIN2999 & BS21 ISO7/1 & EN10226


    Main parts and materials

    No.Part NameMaterial
    1BodyCast Iron (GG25/GGG-4)
    2BonnetCast Iron ( GG25/GGG-4 )
    3NutCarbon steel
    4BoltingCarbon steel
    5BallStainless steel(SS304/SS316)
    6SeatPTFE/RPTFE/TFM1600
    7GasketPTFE
    8StemStainless steel(SS304/SS316)
    9Stem packingPTFE
    10Gland flangeCast Iron (FC200)
    11Stop collarCarbon steel
    12CirclipSteel
    13LeverDuctile iron (FCD450)
    14Gland boltlCarbon steel
